Sugar Coating Machine

Name: Sugar Candy Coating Machine
Model:XT-SCP
Material:SUS304
Voltage: 380V 50HZ 3Phase /220V
Capacity: 100kg/h
Power: 0.55kw
Dimension: 1000*1500*1700mm
Output Products: Sugar Coated Peanut
WhatsApp: +86 13954503673
WhatsApp: +86 18906425332
E-mail: sales@xtpeanutmachine.com
E-mail: sales001@xtpeanutmachine.com
Contact us
Get a Quote

Product Details

Sugar Coating Machine is mainly used for making pellet, coating film on tablets. It can also be used for making ball shape products or granules, mixing, and polishing, etc.

Such as: chocolate polishing, peanut coating, coating sugar, adding flavor, producing pearl dumplings, and pelletizing the desiccant& aluminium hydroxide, porcelain ball making, etc.

This machine consists of main body, worm wheel box, coating pan, heating device, blower, blower, electrical equipment, etc. The transmission process that the motor drive the worm wheel and worm via triangle belt make the coating pan rotate.Then the material erithe and revolve up and down in the coating pan, so that even mixing, pelletizing and polishing can be completed well.


Feature:

1 This machine is a special equipment which is used to coat the chocolate,flour and sugar to form the shape.

2 The coated peanuts are round and smooth:

3 It also can process almond, cashew, soybeans and so on.

This equipment has been up to the export processing standard.


Model

Dia sugarcoating dish（mm）

Capacity kg/time

Rotation Speed(r/min)

Power of Motor(kw)

Power of Fan(KW)

Power of Heat(KW)

Overall Size(mm)

Weight(KG)

XT-SCP

1000

50-70

32

1.5

0.12

3

1100*1000 *1560mm

220KG


working processing

working processing (2)

FAQ

Q1: I am new to nut processing. How do I determine which supporting equipment should be used on the production line?

A: We can design it for you. Based on your budget, raw materials, workspace size, and production capacity, we can assist you in selecting the most suitable equipment and developing the optimal food production line solution. Simply provide your specific requirements, and we will design the most cost-effective high-quality solution for you.

Q2: How can I learn more about the detailed specifications and quality of your company's nut processing equipment?

A: First, we provide comprehensive product manuals covering all details, including specifications, raw materials, production capacity, and more. This applies to most of our production lines. Second, we can provide you with on-site videos demonstrating the workflow and how mechanical components operate during runtime. Finally, we warmly invite you to visit our factory for an on-site inspection, and we can also recommend local clients for you to visit.

Q3: Can you guarantee your quality?

A: Our products are made of 304 food-grade stainless steel. We strictly control product quality during the production process and test the equipment before shipment to ensure excellent mechanical performance.

Q4: What are your advantages compared with your competitors?

A: With rich industry experience and strict Product Quality Control systems, we provide:
1). Stable and reliable product at reasonable price
2). Good customer service: Fast response to any inquiry or question
3). On-time delivery.

Q5 : What shall we do if breakdown occurs?

A: Please informed us once the breakdown occurs. During warranty period, if breakdown occurs, we shall respond in time after receiving the notification of the buyer. We shall handle failure over the telephone/ fax or arrange relevant personnel to the site according to the buyer’s requirements.

Q6: Why do food machines of the same model vary in price when produced by different manufacturers?

A: Good question! In fact, price differences stem solely from variations in the machines themselves. While they may appear similar in appearance and structure, their quality and lifespan can differ significantly. This is because the thickness of the steel plates varies—thicker plates indicate higher quality. The type of steel used is also a key factor. Additionally, different motor brands can impact production efficiency. Therefore, you should not solely pursue the lowest price.
